Roval Alpinist Cockpit II Integrated Handlebar

Roval Alpinist Cockpit II: integrated carbon handlebar

The Roval Alpinist Cockpit II combines the handlebar and stem in a single high-modulus carbon fibre structure. Designed for road and gravel bikes, it pairs low weight with ergonomic features intended to improve comfort and control while riding.

Its integrated construction creates a clean appearance and a streamlined cockpit setup. It is designed for riders seeking to reduce cockpit weight without compromising comfort on longer rides.

Retül and Body Geometry ergonomics

The handlebar tops have been developed using Retül and Body Geometry data. The D-shaped ergonomic profile provides 12% more surface area in the upper section than the previous generation, offering a larger contact area for the hands.

The geometry features a 75 mm reach, a 125 mm drop and 4° of flare at the drops. These dimensions help define hand positioning and control while riding.

Comfort and vibration damping

The Roval Alpinist Cockpit II delivers a stated 28.3% increase in damping compared with the Roval Rapide Cockpit. This feature is designed to improve comfort on longer rides by helping reduce vibrations transmitted from the road surface.

The stated weight is 270 g for the 400 mm handlebar and 100 mm stem configuration. Actual weight may vary depending on the selected size.

Cable routing and compatibility

The cockpit is designed to accommodate cable routing for Shimano, SRAM and Campagnolo systems. Before purchasing, check compatibility with your bicycle's frame, headset and cable-routing system.

The Roval Alpinist Cockpit II is not compatible with clip-on aero extensions. The package includes the Roval bolt-on computer mount, top cap and steerer tube bolt.

Roval Alpinist Cockpit II technical specifications

• Type: integrated handlebar and stem
• Material: high-modulus carbon fibre
• Use: road and gravel bikes
• Stated weight: 270 g in the 400 x 100 mm configuration
• Handlebar tops: D-shaped ergonomic profile, developed using Retül and Body Geometry data
• Width at the hoods: 380, 400, 420 or 440 mm
• Width at the drops: 396, 416, 436 or 456 mm, depending on handlebar width
• Reach: 75 mm
• Drop: 125 mm
• Flare: 4°
• Stem length: 80–130 mm, depending on handlebar width
• Stem angle: -6°
• Steerer diameter: 1-1/8"
• Steerer clamp height: 40 mm
• Steerer bolts: titanium, 5 Nm torque
• Cable routing: compatible with Shimano, SRAM and Campagnolo systems
• Clip-on aero extension compatibility: no
• Maximum rider weight: 125 kg
• Included accessories: Roval computer mount, top cap and steerer tube bolt
• Warranty: limited lifetime warranty, subject to the manufacturer's terms
• EAN: 196625240478
• MPN: 21026-0323

Compatibility note: check the selected dimensions and compatibility with your bicycle frame and cable-routing system before purchasing. This cockpit is not compatible with clip-on aero extensions.
